AZIMUTH SERVO SYSTEM
   - analogue servo type
   - AC servo motor + gear
   - ass'y + azimuth transmitter

LEVEL SERVO
   - analog servo type
   - AC servo motor + gear ass'y

SPEED ERROR CORRECTION
   - correcting master card and transmitter by
      2'nd servo ass'y

LATITUDE ERROR CORRECTION
   - calulating by analogue circuit

      OUTPUT   - azimuth angle repeater signal step signal 12 ch'

      SLIP RING   - transmit pick-up low level signal
                                   - 9 channel

      OPTION     - analog signal synchro x 1
